Description
Rim Diameter Capacity: 14″ to 26″
Maximum Wheel Weight: 500 kg
Maximum Wheel Width: 780 mm (78 cm)
Maximum Tyre Diameter: 1,600 mm (160 cm)
Maximum Wheel Diameter: Ø1,600 mm
Wheel Capacity: Suitable for wheels weighing up to 500 kg, with a maximum diameter of 1,600 mm and a maximum width of 780 mm.
Mounting Speed: Single speed, approximately 9 RPM
Operation: Electric-hydraulic
Hydraulic Pump Motor: 1.5 kW, 380 V, 3-phase. A 220 V option is available.
Gearbox Motor: 2.2 kW, 380 V, 3-phase. A 220 V option is available.
Total Motor Power: 3.7 kW combined rated motor power
Bead Breaker Force: 2,500 kg (24.515 kN)
Maximum Torque: 6,457 N·m
Control Voltage: 24 V
Power Supply: 230/400 V, 50/60 Hz
Electrical Configuration: 1-phase or 3-phase, depending on the selected configuration
Voltage Options: 220 V optional
Machine Weight: 517 kg
Overall Dimensions: 2,500 × 2,000 mm
Maximum Wheel Specifications: The machine is designed to handle wheels weighing up to 500 kg, with a maximum tyre/wheel diameter of 1,600 mm and a maximum wheel width of 780 mm.
Hydraulic System: Hydraulic-powered wheel handling and bead-breaking system, driven by a 1.5 kW hydraulic pump motor.
Transmission System: Gearbox-driven rotation system powered by a 2.2 kW motor, providing a maximum torque of 6,457 N·m.
Control System: 24 V low-voltage control system for machine operation.
Electrical Frequency: 50/60 Hz
